System Requirements
• Windows XP SP2 or 2000 SP4
• CD-ROM drive
• 20 MB of free hard disk space
• A free USB-port

Standards
• IEEE 802.11n
• IEEE 802.11g
• IEEE 802.11b
• USB 2.0

Frequency band
• From 2412 to 2483.5 MHz

Encoding method
• DSSS, OFDM

Modulation schemes
• DBPSK, DQPSK, DSSS and CCK (BPSK/QPSK/16-QAM/64-QAM/OFDM)

Wireless Speed ​​*
• 802.11g: 6/9/12/18/24/36/48/54 Mbit / s
• 802.11b: 1/2/5.5/11 Mbit / s
• 802.11n: 30/60/90/120/180/240/270/300 Mbit / s

Receiver Sensitivity
(802.11b, PER 8%)
• 11Mbps / s:-89dBm
• 1, 2, 5.5, 11 Mbit / s:-91dBm

Receiver Sensitivity
(802.11g, PER 10%)
• 6Mbps / s:-90dBm
• 9 Mbit / s:-89dBm
• 12 Mbit / s:-87dBm
• 18 Mbit / s:-85dBm
• 24 Mbit / s:-82dBm
• 36 Mbit / s:-79dBm
• 48 Mbit / s:-74dBm
• 54 Mbit / s:-73dBm

Transmitter output power (typical)
• 18dbm (802.11b)
• 14dbm (802.11g)
• 14dbm (802.11n)

Antenna
• Two built-in antennas

Security
• 64/128-bit WEP-encryption
• Wi-Fi Protected Access (WPA / WPA2)

Operating voltage
• 5 VDC + / - 10%

Power Consumption (802.11n)
• TX: 460mA
• RX: 280mA

Indicator
• Activity
